Product Details
＋
9000N
Developed to be the perfect digital streaming companion for the flagship audiolab 9000 series, the new 9000N is the result of over three year’s development and innovation to provide a critically stable, high-resolution wireless (and wired) digital music playback.
| Model | 9000N |
| General Description | Network Player |
| Design Philosophy And Core Technology | ESS Sabre ES9038Pro 32bit DAC Quad Arm® Cortex®-A53 core,1.8GHz per Core Audiolab 9000N Streaming technology (IEEE 802.11 a / b / g / n / ac,2.4/5GHz) UPnP AV protocol with audio streaming extension (Open Home) Built-in Certified MQA Full decoder (via streaming & PC USB) Native support for Spotify Connect, TIDAL Connect, MQA, Qobuz and TuneIn Radio Roon Ready Gapless Playback High-resolution album artwork display USB storage / flash drive / USB hard disk (Single-partition FAT32, exFAT and NTFS) playback 4.3" (800 x 480px) IPS LCD screen iOS (11.0 or later) / Android (Android 4.0 or later) required for App control |
| The audiolab 9000N App Features | Native support for TIDAL, MQA, Qobuz and TuneIn Radio Tidal MQA icons to easily identify high-res music Qobuz high-res icons to identify high-res music Volume control High-resolution album artwork display Artwork caching Intelligent search functionality Multiple Playlist complications & functionality Multiple tag handling Composer tag support Album-grouping in playlist Automatic internet links to artists / album / songs Saving and restoring of playlists (including Tidal and Qobuz) |
| Inputs | 1 x Network Streaming 1 x PC USB (USB Type-B) 1 x Ethernet 10/100 / 1000 Base-T Ethernet 1 x 12V Trigger |
| Outputs | 1 x RCA (pair) 1 x XLR (pair) 1 x Optical 1 x Coaxial 1 x 12V Trigger (Link) |
| Supported File Formats | DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD) PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF Compressed (lossy) Audio: MP3 MQA |
| Sampling Frequency | PCM: 44.1kHz-768kHz (705.6kHz / 768kHz Fixed-point supported via Audiolab 9000N App streaming) DSD: DSD64, DSD128, DSD256, DSD512 (Native) |
| Digital Section | |
| Digital Output Voltage | 500mV /- 50mVpp |
| Output Impedance | 75Ω |
| Frequency Response | -0.01dB (20Hz - 20kHz, ref.1kHz) |
| Max. Sampling Frequency | 192kHz / 24bit |
| Digital Outputs | 1 x Coaxial , 1 x Optical |
| D to A Converter | |
| Variable Output Voltage | 0 – 2.05V |
| DAC | ES9038Pro |
| Frequency Response | /-0.5dB (20Hz - 20kHz, ref.1kHz) |
| Total Harmonic Distortion | <0.001% (1kHz @ 2.05Vrms) |
| Max. Sampling Frequency | 768kHz / 32bit |
| Signal-to-noise ratio (A-weighted) | >116dB(RCA), >120dB(XLR) |
| Output Impedance | 120Ω |
| General | |
| Standby Power Consumption | <0.5W |
| Net Weight | 6.2kg |
| Gross Weight | 8kg |
| Dimensions (mm)(W x H x D) | 444 x 89 x 333 |
| Carton Size (mm)(W x H x D) | 514 x 470 x 161 |
| Finish | Black / Silver |
| Power Requirements (depending on region) |
220-240V ~ 50/ 60Hz 100-120V ~ 50/ 60Hz |
| Safety Regulation Conformity | |
| Standard Accessories | Power Cord, Remote Control, User Manual |
